Place of Origin: | Shenzhen,China |
---|---|
Brand Name: | guangzhi |
Certification: | CE、FCC、RoHS |
Model Number: | GZ-K002023-40 |
Minimum Order Quantity: | 1pcs |
Price: | To be quoted |
Packaging Details: | Individual product package size:235*150*50mm, Carton Size:482*320*275; |
Delivery Time: | 10-20 work days |
Payment Terms: | T/T,Paypal |
Supply Ability: | 100000pcs |
Application: | Banking System, Commercial POS System, Attendance Access Control System And Member Management System | Connection: | USB |
---|---|---|---|
Material: | Abs | Weight: | 121g |
Size: | 140mm*43.5mm*41.5mm | Working Temperature: | -20°c ~ 60 °c |
Highlight: | pos card reader,contactless rfid reader |
Magnetic card standard |
ISO7811/7812 |
Product size |
140mm*43.5mm*41.5mm |
Card thickness |
0.76 mm±0.08 mm |
Card reading method |
F2F |
Card swipe speed |
10-150cm/sec (4-60inch/sec) |
Recording density |
TK1=210;TK2=75;TK3=210(BPI |
Power supply voltage |
USB interface power, DC5V ± 5% |
Power supply fluctuation |
50mVp-p max |
Current |
65mA(max) |
Weight |
RC4100≈190g; HRC4200≈100g |
Head life |
≥500,000 times |
Track width |
1.5mm |
Operating position |
indoor |
Interface method |
USB |
Appearance |
Indicator 1: Green LED, light indicates correct card reading |
|
2: Red LED, light indicates card reading error |
Working temperature |
-20~50°C |
Operating humidity |
20%~90% RH |
Storage temperature |
-30~70℃ |
Storage humidity |
0%~95% RH |
SS |
Magnetic card data |
ES |
CR |
TK |
% |
DATA |
? |
0x0d |
First track |
; |
DATA |
? |
0x0d |
Second track |
+ |
DATA |
? |
0x0d |
Third track |
