Metal Embedded Numeric Keypad With Various Pattern Panel Customized Dimension

Basic Information
Place of Origin: SHENZHEN CHINA
Brand Name: szguangzhi
Certification: CE、FCC、RoHS、IP67
Model Number: GZ-Z010250A-001
Minimum Order Quantity: 1pcs
Price: To be quoted
Packaging Details: Individual product package size:235*150*50mm, Carton Size:482*320*275;
Delivery Time: 10-25 work days
Payment Terms: T/T
Supply Ability: 1000000pcs
Detail Information
Application: Telecommunication Equipment, Computer Keyboard, Home Appliance, ATM, Remote Controller Product Name: Keypad, Stainless Steel ATM Keyboard, Mini Usb Wired 19 Key Digital Numeric Keypad, ATM PINPAD, Custom Numeric Keypad
Warranty: 1YEAR Keypad Button Material: Metal
Name: Wireless Numeric Keypad Connector: 2.54mm Female Connector, 8 Pin
Highlight:

industrial metal keyboard

,

custom font keyboard


Product Description

Stainless steel metal keyboard , the panel can be etched with various patterns and colors

Prod uct Name:Metal Numeric Keypad

Product P/N:GZ-Z010193-001

 MECHANICAL DATA

Model Number

JXPC40

Switching material

carbon-on-Gold key switch technology PCB

Actuation Force

2.0 N+/-0.1N (pressure point)

Frame/keys materials

Stainless steel 304

Dimensions

Customize

Key Size

15.0mm *20.0mm

Key Travel

0.45mm

Key life

more than 1 million of operations

G.W.

750g approx

ELECTRICAL DATA

Power supply voltage

 0-24V DC

Current Rating

appr. 20mA

Contact resistance

5 ohm (max)

Electrical lifetime

> 5 years

Interface

USB/ PS2

OS

All windows, Linux, Unix, Mac OSX

ENVIRONMENTAL ADAPTABILITY

Operating temperature

-20 to +75

Storage temperature

-35 to +85

Operating RH

30-90%RH

Atmospheric pressure

60-106Kpa

RELIABILITY

Protection Level

IP65(front panel)

Vandal resistant

IK09

Packaging & Shipping



PACKAGING

Inner Box

1Set

Carton

20Sets

Carton Size

Customized

Carton G.W.

1KG
