Matrix Type Industrial Numeric Keypad Ip65 Watertight For Access Control System

Basic Information
Place of Origin: Shenzhen,China
Brand Name: guangzhi
Certification: CE、FCC、RoHS
Model Number: GZ-Z010200-001
Minimum Order Quantity: 1pcs
Price: To be quoted
Packaging Details: Individual product package size:235*150*50mm, Carton Size:482*320*275;
Delivery Time: 10-20 work days
Payment Terms: T/T, Paypal
Supply Ability: 100000pcs
Detail Information
Application: ATM, Self-service Equipment, Game Consoles, Access Control, Medical Equipment, Military Equipment, Marine Equipment, Mine Equipment, Etc. Connection: USB,PS2,R232,8P
Material: Stainless Steel Certification: CE, FCC, CE And FCC Certified, RoHS
Number Of Keys: 16 Storage Temperature: -40°C To +85°C (-40°to 185°F), -40°C (-40°F) To +70°C (158°F)
Highlight:

automatic gate keypad

,

wired numeric keypad


Product Description

16 key matrix ip65 metal button numeric door access control system keypad



Product Name: industrial metal keyboard



Product Number

GZ-Z010200-001

Key

16 keys

Key Travel

0.5mm

Installation Size

100*100mm(front Panel)

Product Weight

0.5KG

Interface Mode

USB , PS2, R232, 8P Matrix Interface

Installation Method

Install from the outside to the inside



ELECTRICAL DATA

Power supply voltage:  0-24V DC

Current Rating:appr. 20mA

Contact resistance:5 ohm (max)

Electrical lifetime:> 5 years

Interface:Matrix Male pinout connector 7PIN 2.54mm Or customize PS2/USB/RS232

All windows, Linux, Unix, Mac OSX  ENVIRONMENTAL ADAPTABILITY

Operating temperature:-20℃ to +75℃

Storage temperature:-35℃ to +85℃

Operating RH:30-90%RH

Atmospheric pressure:60-106Kpa

RELIABILITY:

Protection Level

IP65(front panel)

Vandal resistant

IK09
