Laser Engraving Industrial Numeric Keypad For Industrial Equipment Control

Basic Information
Place of Origin: SZENZHEN CHINA
Brand Name: guangzhi
Certification: CE、FCC、RoHS、IP65
Model Number: GZ-B005020-009
Minimum Order Quantity: 1pcs
Price: To be quoted
Packaging Details: Individual product package size:235*150*50mm, Carton Size:482*320*275;
Delivery Time: 1-20work days
Payment Terms: T/T
Supply Ability: 10000
Detail Information
Connection: USB,PS2,R232,8P Material: Stainless Steel
Application: ATM, Self-service Equipment, Game Consoles, Access Control, Medical Equipment, Military Equipment, Marine Equipment, Mine Equipment, Etc. Size: 87.5*91.5mm
Certification: CE, FCC, CE And FCC Certified, RoHS Storage Temperature: -40°C To +85°C (-40°to 185°F), -40°C (-40°F) To +70°C (158°F)
High Light:

automatic gate keypad

,

wired numeric keypad


Product Description

Designed industrial metal numeric keyboard with alphanumeric buttons

Product Name:Industrial Numeric Keypad

Product P/N:GZ-B005020-009

Product Size:87.5*91.5mm

Product Description: It is stainless steel keypad of waterproof and dustproof, adopt rubber designing, and with digital keys and 6 function keys, the keys are compact layout and it with 2.0mm long-travel,. It is assembled from inside to outside, the total thickness is 28mm(Including bottom case); It adopts the design of whole stainless steel overlay, rubber keys and laser engraving, and with the precision tooling, the surface treatment beautiful and magnificent.

ELECTRICAL DATA

· Supply Voltage: +5V DC +/-5%

· Current Rating: appr. 30mA

· EMC Standard: It is compliance with the council EMC directive 89/336/EEC EN55022:1988+A1:2000+A2:2003 EN55024: 1988+A1:2001+A2:2003

· Emission: EN 50081-1

· Immunity: EN 50082-1

· Lifespan>5 years

· Switch Contact Material: Carbon-on-Gold key switch technology PCB.

· Interface: PS2, USB available.

· OS: DOS/Windows95/98/NT/ME/2000/2003/XP/Vista/win7/win8/win9/win10, Linux, Unix, Mac OSX

ENVIRONMENTAL ADAPTABILITY

· Operating temperature:-20oC to +60oC

· Storage temperature: -30oC to +70oC

· Operating RH: 30-90%

· Atmospheric pressure: 60-106Kpa.

· Saline mist: 96 hours, IEC 60512-6

· Damp heat test at + 40oC: 21 days, IEC 60512-6

· Dry heat test at + 85oC: 10 days, IEC 60512-6

Laser Engraving Industrial Numeric Keypad For Industrial Equipment Control 0



Laser Engraving Industrial Numeric Keypad For Industrial Equipment Control 1





Laser Engraving Industrial Numeric Keypad For Industrial Equipment Control 2



Laser Engraving Industrial Numeric Keypad For Industrial Equipment Control 3
