| Place of Origin: | SHENZHEN CHINA |
|---|---|
| Brand Name: | szguangzhi |
| Certification: | CE、FCC、RoHS、IP67 |
| Model Number: | GZ-Z010193-001 |
| Minimum Order Quantity: | 1pcs |
| Price: | To be quoted |
| Packaging Details: | Individual product package size:235*150*50mm, Carton Size:482*320*275; |
| Delivery Time: | 1-20 work days |
| Payment Terms: | T/T |
| Supply Ability: | 1000000pcs |
| Application: | Telecommunication Equipment, Computer Keyboard, Home Appliance, ATM, Remote Controller | Product Name: | Keypad, Stainless Steel ATM Keyboard, Mini Usb Wired 19 Key Digital Numeric Keypad, ATM PINPAD, Custom Numeric Keypad |
|---|---|---|---|
| Warranty: | 1YEAR | Interface: | USB |
| Name: | Wireless Numeric Keypad | Connector: | 2.54mm Female Connector, 8 Pin |
| High Light: | embedded keyboard,industrial metal keyboard |
||
|
MECHANICAL DATA |
|
Model Number |
JXPC40 |
keys |
40 keys |
Switching material |
carbon-on-Gold key switch technology PCB |
Actuation Force |
2.0 N+/-0.1N (pressure point) |
Frame/keys materials |
Stainless steel 304 |
Dimensions |
200mm*84mm |
Key Size |
14.0mm *14.0mm 21.0mm *14.0mm |
Key Travel |
0.45mm |
Key life |
more than 1 million of operations |
G.W. |
750g approx |
ELECTRICAL DATA |
|
Power supply voltage |
0-24V DC |
Current Rating |
appr. 20mA |
Contact resistance |
5 ohm (max) |
Electrical lifetime |
> 5 years |
Interface |
USB/ PS2 |
OS |
All windows, Linux, Unix, Mac OSX |
ENVIRONMENTAL ADAPTABILITY |
|
Operating temperature |
-20℃ to +75℃ |
Storage temperature |
-35℃ to +85℃ |
Operating RH |
30-90%RH |
Atmospheric pressure |
60-106Kpa |
RELIABILITY |
|
Protection Level |
IP65(front panel) |
Vandal resistant |
IK09 |
PACKAGING |
|
Inner Box |
1Set |
Carton |
20Sets |
Carton Size |
41*24*25.5CM |
Carton G.W. |
17KG |
